The Jetour T1 was produced in 2024, 2025, 2026, 2027, 2028, 2029, and 2030. It is also known as the Jetour Freedom. In this post, we will describe the Jetour T1 fuses and relays, including block diagrams, their locations, and photo examples. We will highlight the fuse responsible for the cigarette lighter.
The purpose of fuses and relays may differ from those presented and depend on the year of manufacture, the level of electrical equipment and the region of delivery of your vehicle.
Passenger compartment
Inside the car, the fuse and relay box is located at the bottom of the instrument panel behind a plastic protective cover.
To access it, you need to remove the speaker cover (start with the two latches at the bottom) or remove the entire bottom panel.
Diagram
Assignment
| 1 | 15A Rear wiper relay |
| 2 | 10A Heated outside mirrors |
| 3 | 30A Heated rear window |
| 4 | 25A 220V inverter |
| 5 | 15A Reserve |
| 6 | 20A Automatic parking assist (APA), driver and front passenger footwell lamps |
| 7 | 5A Automatic parking assist (APA), ETC |
| 8 | 7.5A Driver and front passenger seat ventilation |
| 9 | 10A Heating and air conditioning system, instrument panel USB port, negative ion generator, ultraviolet emitter, PM2.5 sensor |
| 10 | 7.5A Ambient lighting, ambient light controller, rear microwave radars, rear collision warning radars, blind spot detection (BSD), driver and front passenger footwell lamps |
| 11 | 15A Audio/multimedia system |
| 12 | 7.5A Reserve |
| 13 | 20A Overhead control panel, interior lighting |
| 14 | 7.5A Diagnostic interface, IOV, system GLONASS, Telematics Box |
| 15 | 7.5A Automatic Transmission Control Unit (7DCT) |
| 16 | 10A Bluetooth Module, Low Configuration Logo Light |
| 17 | 10A Instrument Cluster, Central Display |
| 18 | 10A Reserve |
| 19 | 7.5A Rain Sensor, Body Control Module (BCM), Electronic Limited-Slip Differential, Torque Management System, Body Domain, Multi-Function Camera, Automatic Parking Assist (APA) |
| 20 | 7.5A Angle Sensor |
| 21 | 7.5A Diagnostic Interface, IOV, GLONASS System, Telematics Box |
| 22 | 10A Head Unit for Communication, Brake Fluid Level Sensor, Oil Pressure Switch, Driver and Front Passenger Seat Belt Warning |
| 23 | 7.5A Electric Power Steering (EPS) |
| 24 | 10A Electronic Gear Shift, Gear Display, Drive Mode Switch, Front Ford Radar, Second-Row Heated Seat Switch |
| 25 | 10A Engine Compartment Fuse and Relay Box |
| 26 | 5A Airbag Controller |
| 27 | 10A Roof Tent |
| 28 | 10A Body Control Module (BCM) |
| 29 | 10A Front USB |
| 30 | 15A Wireless Charging, Front Backup Power, Front Power Outlet |
| 31 | 15A Reserve |
| 32 | 15A Reserve |
| 33 | 15A Reserve |
| 34 | 7.5A Reserve |
| 35 | 7.5A Spiral Cable, Steering Wheel Vibration, Steering Wheel Heated |
| 36 | 7.5A 220V Inverter, ETC, Audio/Multimedia System, Inside Rearview Mirror |
| 37 | 10A Reserve |
| 38 | 7.5A Reserve |
| 39 | 10A Reserve |
| 40 | 7.5A Rear Backup Power |
| 41 | 10A Wireless Charging |
| Power fuses | |
| H1 | Reserve |
| H2 | 20A Power Tailgate |
| H3 | 30A Power Driver Seat, Power Front Passenger Seat |
| Relays | |
| R1 | Reserve |
| R2 | Rear Wiper Relay |
| R3 | Rear Window and Mirror Defogger Relay |
| R4 | Ignition Relay ACC1 |
| R5 | Ignition Relay ACC2 |
| R6 | Reserve |
| R7 | Ignition Relay IGN |
Fuse number 30, 15A, is responsible for the operation of the front cigarette lighter.
Engine compartment
Under the hood, in the engine compartment, the main block with fuses and relays is located on the left side, next to the battery and is covered with a protective cover.
Check the information against your diagram on the back of the unit cover.
Diagram
Description
| H1 | Spare |
| H2 | 80A Electric Power Steering (EPS) |
| H3 | Spare |
| H4 | Spare |
| H5 | 175A Alternator |
| H6 | Spare |
| H7 | 80A Gauge Power Supply 2 |
| H8 | 100A Gauge Power Supply 1 |
| H9 | Spare |
| EF01 | 40A Electronic Stability Program (ESP) |
| EF02 | 60A Automatic Transmission Control Unit (TCU, 7DCT) |
| EF03 | 5A Electronic Stability Program (ESP) |
| EF04 | 5A Brake Switch |
| EF05 | 10A Engine Control Unit (ECU), Transmission Control Unit (TCU) |
| EF06 | 7.5A Forward Radar Module (FRM) |
| EF07 | Spare |
| EF08 | Spare |
| EF09 | 7.5A Energy Saver Power Supply |
| EF10 | 10A Right High Beam |
| EF11 | 10A Left High Beam |
| EF12 | 7.5A Lighting Fuse |
| EF13 | 10A Right Low Beam, Headlight Adjustment |
| EF14 | 10A Left Low Beam, Headlight Adjustment |
| EF15 | Spare |
| EF16 | Spare |
| EF17 | 60A Blower Fan Variable speed control |
| EF18 | 30A Front wiper motor |
| EF19 | 30A Blower relay |
| EF20 | 40A Electronic stability program (ESP) |
| EF21 | 30A Starter |
| EF22 | 30A Anti-pinch system, power windows 1 |
| EF23 | 30A Anti-pinch system, power windows 2 |
| EF24 | 20A Torque management system |
| EF25 | 20A Electronic limited slip differential (LSD) |
| EF26 | 25A Backup power supply |
| EF27 | 15A Vacuum pump relay |
| EF28 | 20A Fuel pump |
| EF29 | 5A Brake switch |
| EF30 | 10A A/C compressor |
| EF31 | 15A Central electronic module (CEM) |
| EF32 | 25A Central electronic module (CEM) |
| EF33 | 20A Central electronic module (CEM) |
| EF34 | 10A Engine management system (EMS) |
| EF35 | 25A Central electronic module (CEM) |
| EF36 | 15A Horn |
| EF37 | 5A Relay coil |
| EF38 | Backup |
| EF39 | 5A Start feedback |
| EF40 | 25A Steering column lock, washer Glass, Fuel Filler Cap |
| EF41 | Spare |
| EF42 | 15A Automatic Transmission (8AT) |
| EF43 | 20A Electric Shift Motor, Automatic Transmission (8AT) |
| EF44 | 5A Electric Parking Brake (EPB) Switch, Automatic Transmission (7DCT) |
| EF45 | Spare |
| EF46 | Spare |
| EF47 | 20A Horn Module |
| EF48 | 15A Engine Management System (EMS) |
| EF49 | 15A Ignition Coils |
| EF50 | 10A Front O2 Sensor |
| EF51 | 10A Electronic Thermostat, PCV Valve Heater, Variable Oil Pump, Hydraulic Control Valve |
| EF52 | 15A Engine Sensor |
| EF53 | 10A Electric PWM Pump, Cooling Fan |
| EF54 | Spare |
| EF55 | Spare |
| EF56 | Spare |
| EF57 | Spare |
| R1 | Spare |
| R2 | Spare |
| R3 | Main Relay, Engine Control Module |
| R4 | High Beam Relay |
| R5 | Low Beam Relay |
| R6 | Windshield Heated Relay |
| R7 | Windshield Heated Relay |
| R8 | Heater Relay |
| R9 | Horn Relay |
| R10 | Rear Backup Power Relay |
| R11 | Spare |
| R12 | Relay Starter |
| R13 | Engine Drive Circuit Status Relay |
| R14 | Reserve |
| R15 | Reserve |
| R16 | Vacuum Pump Relay |
| R17 | Reserve |
| R18 | Fuel Pump Relay |
| R19 | Air Conditioning Compressor Relay |
A high-power fuse block and intelligent battery charging system (5A) can be mounted on the positive terminal.
