The Nissan Quest V41 represents the second generation of the Quest model range, which was produced in 1998, 1999, 2000, 2001, 2002, 2003. During this time, the model underwent an update. In this post, you will find a description of the fuses and relays of the Nissan Quest 2G with fuse box diagrams, their locations, and photo examples. Let’s highlight the cigarette lighter fuse.
The purpose of fuses and relays may differ from that described and depends on the year of manufacture and the level of electrical equipment in your vehicle.
Passenger compartment
Layout
In the passenger compartment, the fuse box with fuses and relays is located at the bottom of the dashboard behind the glove compartment.
Diagram
Assignment
| 1 | 7,5A Front Heated Seats |
| 2 | 10A Transmission Control Module (TCM), Rear Wiper Motor, EATC Unit |
| 3 | 10A Air Bag Diagnosis Sensor Unit |
| 4 | 10A IACV-AAC Valve, Vacuum Cut Valve Bypass Valve, Engine Control Module (ECM), Data Link Connector, Map/Baro Switch Solenoid Valve, Throttle Position Sensor, EVAP Canister Vent Control Valve |
| 5 | 7,5A Door Mirror Remote Control Switch, SECU |
| 6 | 20A Cigarette Lighter |
| 7 | 20A Rear Power Point |
| 8 | 20A Front Wiper Motor, Front Washer Motor, Front Wiper Amplifier |
| 9 | 10A Rear Wiper Motor, Rear Washer Motor |
| 10 | 15A 2001-2002: Audio, Video Monitor, Subwoofer Amplifier |
| 7,5A 1998-2000: Audio | |
| 11 | 20A 2001-2002: Rear Power Point (Console Mounted) |
| 20A 1998-2000: Subwoofer Amplifier | |
| 12 | 7,5A Headlamp Control Unit, Engine Control Module (ECM) |
| 13 | 7,5A Air Conditioner Control Unit, Air Conditioner Relay, EATC Unit, Air Mix and Mode Door, IACC-FICD Solenoid Valve |
| 14 | 20A Rear Window Defogger |
| 15 | 20A Rear Window Defogger |
| 16 | 10A Rear Window Defogger Switch, Mirror Heaters |
| 17 | 10A Front Side Marker Lamps, Front Combination Lamp, Combination Switch |
| 18 | 7,5A Illumination Lamps |
| 19 | 10A Rear Combination Lamp, Trailer License Lamp |
| 20 | 10A Audio, CD Changer, Rear Audio Remote Control Unit, FES Control Panel |
| 21 | 15A Interior Lamps, Memory Seat and Mirror Control Unit, Sunroof Motor |
| 22 | 20A Stop Lamp Switch, Trailer Tow Control Unit |
| 23 | 10A Hazard Switch, Security Indicator Lamp |
| 24 | 15A Rear Blower Motor |
| 25 | 15A Rear Blower Motor |
| 26 | 7,5A Heated Oxygen Sensor |
| 27 | 10A Hazard Switch |
| 28 | 20A Front Blower Motor, Front Blower Speed Control Unit |
| 29 | 10A Data Link Connector, Combination Meter, ASCD Brake Switch, Air Conditioner Relay, Cooling Fan Relay, Rear Blower Motor Relay, Memory Seat and Mirror Control Unit, ASCD Control Unit |
| 30 | 10A ABS Actuator and Electric Unit, Park/Neutral Position Switch, Headlamp Control Unit, SECU, Transmission Control Module (TCM) |
| 31 | 20A Front Blower Motor, Front Blower Speed Control Unit |
| 32 | – |
| Relay | |
| R1 | Tail Lamp |
| R2 | Ignition |
| R3 | Accessory |
| R4 | Rear Window Defogger |
| R5 | Blower |
The fuse number 6 is responsible for the lighter.
Engine compartment
The two boxes with fuses and relays are located on the left side, under a protective cover.
Fuse box
Location
Diagram
Designation
| 33 | 10A Injectors, Engine Control Module (ECM) |
| 34 | 10A Engine Control Module (ECM) Relay, Data Link Connector |
| 35 | 10A Generator |
| 36 | 15A Headlamp RH |
| 37 | 15A Headlamp LH |
| 38 | 7,5A Front Fog Lamp Relay |
| 39 | 7,5A SECU, Vehicle Security Relay |
| 40 | – |
| 41 | 20A ABS Solenoid Valve Relay |
| 42 | 15A Horn Relay |
| 43 | 15A Fuel Pump Relay |
| 44 | 7,5A Radiator Fan Sensing |
| 45 | – |
| 46 | – |
| 47 | – |
| A | 100A Ignition Relay (Fuse: “26”, “27”, “29”, “30”), Accessory Relay (Fuse: “5”, “6”, “7”, “8”, “9”), Tail Lmap Relay (Fuse: “17”, “18”, “19”) Fuse: “2”, “20”, “21”, “22”, “23” |
| B | 140A Generator, Fuse: “A”, “C”, “F”, “G”, “38”, “39”, “41”, “42” |
| C | 65A Front Blower Motor Relay (Fuse: “28”, “31”) |
| D | – |
| E | – |
| F | 30A Circuit Breaker 1 (SECU, Power Window Relay), Circuit Breaker 2 (Power Seat) |
| G | 40A ABS Motor Relay |
| H | – |
| I | 45A Rear Window Defogger Relay (Fuse: “14”, “15”, “16”), Fuse: “24”, “25” |
| J | 75A Cooling Fan Relay |
| K | 30A Ignition Switch |
| L | 20A Cooling Fan Relay |
| M | – |
| N | – |
| Relay | |
| R1 | Cooling Fan Relay 1 |
| R2 | Cooling Fan Relay 2 |
| R3 | Cooling Fan Relay 3 |
Relay box
Location
Diagram
Allocation
| R1 | Park/Neutral Position |
| R2 | Fuel Pump |
| R3 | Bulb Check |
| R4 | 2001-2003: Fog Lamp |
| 1998-2000: ASCD Hold | |
| R5 | Vehicle Security |
| R6 | Horn |
| R7 | Air Conditioner |
There is also a video on this topic on our YouTube channel. If you have anything to add, please write in the comments.
